Marca: Agie
Modello: VP4
Anno: 2013
Nr Serie: 5910340010138
Marca: Agie
Modello: VP4
Anno: 2013
Nr Serie: 5910340010138

Caratteristiche & Attrezzatura

Caratteristiche
RACES - X, Y, Z axis: 800 x 550 x 525 [mm] - U, V axes: 800 x 550 [mm] - Max. taper: 30/500 [°/mm] PART - Max. workpiece dimensions: 1300 x 1000 x 510 [mm] - Max workpiece weight: 3000 [kg] WIRE GUIDE - Wire diameter: 0.15 - 0.33 [mm] POWER SUPPLY - Supply voltage: 400 [V] - Installed power: 12.8 [kVA] DIMENSIONS - Floor dimensions: 2,900 x 3,050 [mm] - Machine height : 2.850 [mm] - Machine weight : 6.870 [kg] MACHINE HOURS - Working hours : 30 593 [h]
Attrezzatura
- CN Agievision V - 15' colour screen - IPG generator - VPC - Retractable tray - SF MODULE - 0.1' RA super finishing module - AC GEO - DXF import - USERSEQUENCE - Machining strategy - R MODULE - 0.2 RA module - FAST THREADING - CONIC PLUS - SMART THREADING - Threading strategy
Specifiche tecniche per il download
